Pipe Layout

• Piping Design in 3D including administration & modeling for Units, Interplant & Offsite for Greenfield & Revamp projects
• Participation in 30%, 60% & 90% and model reviews
• 2D Extraction (layouts , vessel trims etc), Isometric Generation, BOQ Preparation
• Equipment location Plans, Piping Layout drawings & Isometrics in 2D.
• As-Built Drawings

Pipe Stress Analysis

• Static analysis of piping system connected to different type of static & rotary equipment
• Dynamic analysis of piping system subjected to various dynamic event
• Flow Induced Vibration (FIV) and Acoustic Induced Vibration (AIV) of piping system
• Vibration analysis & trouble shooting during operation & maintenance
• Stress analysis of piping system
